Specifications
| Item Number | 6951 |
| Lot Number | 1 |
| Brand | Engel |
| Model | Victory 860H/460V/450 Combi US |
| Year | 2023 |
| Type | Horizontal Injection Molding Machine |
| Location | USA · Register to see location |
| Catalog | In progress – better pictures & additional specs coming soon |
| Drive Type | Servo-Hydraulic |
| Tonnage | 400 |
| Tie Bar Spacing | Tie-Bar-Less |
| Platen Size | 47.2" x 43.3" |
| Clamp Stroke | 39.4" |
| Ejector Stroke | 9.8" |
| Voltage | 480 |
| Amps | 134 |
| Control | Engel CC300 |
| Clamp Type | Tie-Bar-Less |
| Injection Unit Size | 860H / 460V |
| Screw Diameter | 45mm / 45mm |
Features & additional specifications
Complete With: 2023 Engel easix KR20 R1810-2 6-Axis Robot (20 kg Payload, 1,813 mm Reach) Robot Control Integrated in Machine Control 2-Station Servo Rotary Table, 1,100 mm Dia. 12-Fold Rotating Union (4 Water / 2 Air Circuits) ecodrive Servo-Hydraulic Pumps Hydraulic Core Pull (Stationary Platen) Pneumatic Core Pulls (Stationary & Moving Platens) 24 Zone Mold Heat Control 6-Fold Hydraulic Valve Gate Control Platen Ejector 200 mm Frame Extension Additional Operator Panel RJG eDART Interface iQ Weight Monitor & iQ Melt Control OPC UA / Euromap 77 MES Interface (2) Hopper Loaders 21.4 in³ Injection Capacity, Unit 1 (860H) 17.0 in³ Injection Capacity, Unit 2 (460V) 13,228 lbs Max. Mold Weight
Buying details
Seeing it in person
To set up an inspection, email sales@meadoworks.com.
Fees & payment
A 20% buyer's premium is added to the winning bid.
Payment deadlines and accepted methods are in the sale's Terms of Sale — read them before you bid.
Terms of SalePickup & removal
Approved bidders can request a rigging quote from the sale page.
