1990 Battenfeld BA 300V / 50H
| Item Number | 3410 |
| Brand | Battenfeld |
| Model | BA 300V / 50H |
| Year | 1990 |
| Tonnage | 33 |
| Shot Size OZ. | 1.073 |
| Shot Size Grams | 30.4190135 |
| Platen Size | 16.14" x 18.90" |
| Rotary, Shuttle Or Single Table | Single |
| Vert Or Horiz Injector | Horizontal |
| Tie Bar Spacing | 10" x 10" |
| Clamp Stroke | 18.7" |
| Ejector Stroke | 3.9" |
| Daylight | 18.70 |
| Min/max Mold Height | 5.90 / 14.90 |
| Vert Or Horiz Clamp | Vertical |
| Screw Diameter | 22 mm |
Additional Specifications
Vertical injection molding machine
