Specifications
| Item Number | 6592 |
| Brand | Mazak |
| Model | Integrex 200SY |
| Year | 2000 |
| Type | Mill-turn Machine |
| Location | USA |
Features & additional specifications
Main spindle speed range: 35–5,000 rpm
Main spindle bore: 2.40 in (61 mm)
Spindle nose: JIS A2-6
Main spindle motor: 22 kW
Sub-spindle chuck: 6 in
Sub-spindle speed: 35–5,000 rpm
Sub-spindle motor: 7.5 kW (~10 hp)
Live-tool speed: 15–6,000 rpm
Live-tool motor: 7.5 kW (~10 hp)
Live-tool torque: 45.91 ft-lb
Rapid traverse X/Z/Y: 1,181 / 1,299 / 591 ipm
Max tool length: 250 mm (9.84 in)
Max tool dia: 90 mm (3.54 in) / 120 mm (4.72 in) with adjacent pockets empty
Max tool weight: 7 kg
Coolant tank capacity: 66.1 US gal (250 L)
Chip conveyor and coolant system included
Buying details
Seeing it in person
To set up an inspection, email sales@meadoworks.com.
