This machine has been sold. Want to know when a similar Makino horizontal machining center comes in? Enter your email, or tell us what you need.
Specifications
| Item Number | 4655 |
| Brand | Makino |
| Model | A51NX 4-Axis |
| Year | 2016 |
| Type | Horizontal Machining Center |
| Location | USA |
Features & additional specifications
X-Axis Travel: 22" Y-Axis Travel: 25" Z-Axis Travel: 25" Pallet Size: 15.7" x 15.7" Max. Payload: 880 lbs. Max. Workpiece Size: 24.8" x 35.4" Spindle Speed: 14,000 RPM Spindle Taper: CAT 40 Tool Change Time Tool to Tool: 0.9 seconds Tool Change Time, Chip to Chip: 2.3 seconds Max. Tool Length: 11.8" Max. Tool Diameter: 5.5" Max. Tool Weight: 17.6 lbs. Cutting Feedrate: 1,574 IPM Rapid Traverse (X, Y, Z): 1969 IPM EQUIPPED WITH: Full 4th Axis Makino Professional 6 CNC Control 133-ATC Extension Three Point Support Splash and Chip Shield Lift-up Chip Conveyor and Tank Center Trough w/ Base Coolant Wash Spindle Temperature Controller Overhead Shower Coolant System Fluorescent Work Light
This machine has been sold. Looking for a similar Makino horizontal machining center? We source equipment from plant closings and surplus operations daily.
