Used Foam Injection Molding Machines for Sale
All used injection molding machines (67) →
See all 67 Injection Molding Machines →
2 results
Foam Injection Molding Machines by the numbers
From our own catalog: machines listed now and machines we have sold. Updated every few minutes.
By clamp force
| Clamp force | In stock now | Sold by Meadoworks |
|---|---|---|
| 500–999 tons | 1 | 1 |
| 1,000 tons and up | 1 | 0 |
Looking for Something Specific?
Most of our inventory sells before we can list it online. If you need a specific brand, model, or specification, tell us what you need—we have access to unlisted equipment and machines coming in from plant closures.
Browse Used Foam Injection Molding Machines by Brand
Browse Used Foam Injection Molding Machines by Country
Looking to Sell Your Foam Injection Molding Machines?
Meadoworks is an active cash buyer of used industrial equipment. Get a free valuation from our AMEA-certified appraisers.
About Used Foam Injection Molding Machines
Foam injection molding machines produce lightweight plastic parts by introducing a foaming agent (chemical or physical) into the melt, creating a cellular core structure surrounded by a solid skin. This technology (including foam injection machine, structural foam, and MuCell microcellular foaming) reduces material usage, part weight, and cycle times while maintaining structural integrity.
MuCell technology, licensed by Trexel, uses supercritical nitrogen or CO2 to create a microcellular foam structure with uniform, microscopic cells. This process reduces part weight by 10-20%, eliminates sink marks, reduces clamp force requirements, and improves dimensional stability. Structural foam molding uses a larger cell structure for very thick-walled, lightweight parts.
Structural foam presses Meadoworks has listed include Uniloy machines from 750 to 2,000 tons. Engel, Krauss Maffei and Milacron also build foam-capable presses, some fitted with MuCell / Trexel equipment. Contact us at 800-323-0307.
How to Choose a Used Foam Injection Molding Machine
Structural foam or microcellular
Foam molding puts a blowing agent in the melt so the part has a solid skin and a cellular core. Structural foam uses a chemical agent or nitrogen and often runs at lower cavity pressure, which is why a large part can sit in less clamp than the same part molded solid.
MuCell is a licensed microcellular process that meters supercritical nitrogen or CO2. A press without that gas unit and the license is not a MuCell press. Do not treat the two as the same machine.
The gas unit is the machine
The press still needs shot size, screw, and tie bars that fit the tool. The difference is the dosing unit, the nozzle shutoff, and a mold that can vent the gas. A standard hydraulic press with no gas kit will not make this part because you wish it would.
Ask whether the kit is on the machine or was removed when the license left the plant. Weight cuts of about 10–20% are the microcellular claim, and only when that process is actually on the press.
By clamp force: Typical Used Foam Injection Molding Machine Price Ranges
Under 500 tons: about $40,000–$150,000
500–1,500 tons: about $100,000–$350,000
1,500 tons and up: about $200,000–$600,000+
Platen size and nozzle count (structural foam), the gas unit and its licence (MuCell), shot size in pounds, control and age move the price.
These are typical used-market ranges, not a quote on any machine. For a current figure on a specific machine, request a quote or call 800-323-0307.
By brand
Uniloy-Springfield: Low-pressure, multi-nozzle structural foam presses; we have listed Uniloy-Springfield structural foam presses.
Wilmington Machinery: Structural foam presses for large parts; we have sold Wilmington machines.
Engel and Arburg (MuCell): Standard presses fitted with a Trexel MuCell gas unit for microcellular foam.
Meadoworks track record
Meadoworks has sold more than 2,100 used injection molding machines. Structural foam presses are a small, specialized part of that: we have sold Wilmington Machinery foam presses and have listed Uniloy-Springfield structural foam machines of 750 and 2,000 tons.
Foam Injection Molding Machine Specs to Compare
| Spec | Typical range | Why it matters |
|---|---|---|
| Process | Structural foam or microcellular. The gas, the license, and the screw are not interchangeable. | |
| Clamp (tons) | Structural foam presses often 500–2,000+ tons; MuCell presses any size | Often lower than a solid part of the same size, because cavity pressure is lower. Still has to match the tool. |
| Shot (oz) | The solid equivalent of the part. Foam does not add resin. | |
| Gas unit | Nitrogen or CO2 dosing, and whether it is still mounted and documented. |
Process
Structural foam or microcellular. The gas, the license, and the screw are not interchangeable.
Clamp (tons)
Typical range: Structural foam presses often 500–2,000+ tons; MuCell presses any size
Often lower than a solid part of the same size, because cavity pressure is lower. Still has to match the tool.
Shot (oz)
The solid equivalent of the part. Foam does not add resin.
Gas unit
Nitrogen or CO2 dosing, and whether it is still mounted and documented.
What to Inspect on a Used Foam Injection Molding Machine
Find the gas kit
Valves, the dosing unit, and the nozzle. A bare press is a thermoplastic press.
Ask the license
Microcellular needs the process rights, not only the hardware.
Read the screw
A mixing screw for foam is not every general-purpose screw.
Vent the mold
The tool has to let gas out. The press cannot invent vents.
Related Equipment
- Water Temperature Controllers
Hold the mold at a setpoint
- Desiccant Dryers
Dry the resin before it reaches the screw
More Injection Molding Machines types
Types of Injection Molding
Common Applications
Frequently Asked Questions
What is foam injection molding?
Foam injection molding introduces a foaming agent into the plastic melt to create a cellular structure inside the part. The result is a lighter part with a solid outer skin and foamed core. MuCell microcellular foaming creates very fine, uniform cells for 10-20% weight reduction with minimal impact on mechanical properties. Structural foam molding creates thicker-walled parts with larger cells.
How much does a used structural foam molding machine cost?
Typical used-market ranges: under 500 tons about $40,000–$150,000, 500–1,500 tons about $100,000–$350,000, and 1,500 tons and up about $200,000–$600,000+. Platen size, nozzle count, shot size and age move the price. Call 800-323-0307 for a current figure on a specific machine.
What is a structural foam molding machine?
A low-pressure injection press with large platens and often several nozzles. A blowing agent or nitrogen foams the core of the part, so a thick, rigid part fills at low clamp force — pallets, bins, housings and outdoor equipment parts.
What is the difference between structural foam and MuCell?
Structural foam makes thick (about 1/4 inch and up), low-pressure parts on dedicated large-platen presses. MuCell injects a supercritical gas into a standard injection press to make thin-wall parts lighter and flatter; it needs a Trexel gas unit and a modified screw.
Can I buy a foam injection molding machine for a new product?
Yes, but size it on platen area and shot weight rather than tonnage alone — foam parts are big and light. Tell us the part size and weight and we will look for a press that fits.
