Used Two-Platen Injection Molding Machines for Sale
See all 84 Injection Molding Machines →
5 results
2023 Borche BU3300-V
USA
Borche - BU600T
USA
Lot 2
2018 Krauss Maffei KM 900-12000 GX
Menomonee Falls, WI
Ends Thu, Oct 29, 10:02 AM CT
Lot 7
2015 Engel Duo 650H/330W/200L 500 combi US - 3-Shot
Laval, QC
Ends Thu, Oct 29, 10:12 AM CT
Lot 8
Engel Duo 650H/330W/200L 500 combi US - 3-Shot
USA
Ends Thu, Oct 29, 10:14 AM CT
Looking for Something Specific?
Most of our inventory sells before we can list it online. If you need a specific brand, model, or specification, tell us what you need—we have access to unlisted equipment and machines coming in from plant closures.
Browse Used Two-Platen Injection Molding Machines by Brand
Browse Used Two-Platen Injection Molding Machines by Country
Looking to Sell Your Two-Platen Injection Molding Machines?
Meadoworks is an active cash buyer of used industrial equipment. Get a free valuation from our AMEA-certified appraisers.
About Used Two-Platen Injection Molding Machines
Two-platen injection molding machines replace the traditional four-tie-bar toggle design with a compact two-platen clamp, delivering very high clamp force (typically 500 to 4,000+ tons) in a significantly shorter footprint. This makes them the preferred choice for large parts such as automotive bumpers and fascia, pallets, totes, and large industrial components where floor space is at a premium.
Two-platen designs offer uniform clamp force distribution, fast and consistent mold movements, and excellent platen parallelism for large molds. Leading two-platen presses include the Krauss Maffei CX/GX/MX series, Engel Duo, Milacron MMK, and Haitian Jupiter.
When buying a used two-platen injection molding machine, evaluate clamp tonnage, platen dimensions, tie-bar spacing, daylight, and shot capacity to confirm your mold fits. Meadoworks stocks used two-platen presses for large-part molding — contact us at 800-323-0307.
How to Choose a Used Two-Platen Injection Molding Machine
Floor space at high tonnage
A two-platen press clamps with cylinders on the moving platen and locks the tie bars, instead of a long toggle or a third platen. The machine is shorter. That is why large automotive and industrial tools, often from a few hundred tons upward, sit on two-platen frames. Engel Duo-style machines are the pattern people mean.
You still need the shot, the screw, and a tie-bar opening the mold can pass. Shorter does not mean smaller inside.
Against a toggle
A toggle is usually faster at smaller tons and has a long installed base. A two-platen clamp is the large-tool choice when the bay cannot spare the length of a toggle of the same tons. Clamp force is hydraulic. Treat the oil, the lock nuts, and the tie-bar sensors as the maintenance, not as optional extras.
Daylight on these machines is often generous. Confirm it against the mold open and the part, including a robot reach if the beam is low.
Two-Platen Injection Molding Machine Specs to Compare
| Spec | Typical range | Why it matters |
|---|---|---|
| Clamp (tons) | Often about 500 tons and up | Two-platen earns its place on large tools. A small toggle is a simpler machine under a few hundred tons. |
| Machine length (ft) | The reason to buy this clamp. Compare it to the bay, not only to the tonnage. | |
| Tie-bar spacing (in) | Large molds fail this check more often than they fail the tonnage check. | |
| Shot size (oz) | Big tools need a screw that recovers in the cycle. A small shot unit on a large clamp is a mismatch. |
Clamp (tons)
Typical range: Often about 500 tons and up
Two-platen earns its place on large tools. A small toggle is a simpler machine under a few hundred tons.
Machine length (ft)
The reason to buy this clamp. Compare it to the bay, not only to the tonnage.
Tie-bar spacing (in)
Large molds fail this check more often than they fail the tonnage check.
Shot size (oz)
Big tools need a screw that recovers in the cycle. A small shot unit on a large clamp is a mismatch.
What to Inspect on a Used Two-Platen Injection Molding Machine
Watch the tie-bar lock
The nuts or the clamps that grab the bars have to seat every cycle. A slow or uneven lock is the clamp.
Check oil at the clamp cylinders
Force is hydraulic. Leaks at the moving platen are the wear.
Measure the footprint
Bring the bay length. A two-platen that still does not fit was the wrong reason to choose it.
Confirm shot and screw
Large platens get paired with tired injection units in the used market. Read both.
Related Equipment
- Water Temperature Controllers
Hold the mold at a setpoint
- Servo Robots
Take the part out and place it
More Injection Molding Machines types
Types of Injection Molding
Common Applications
Frequently Asked Questions
What is a two-platen injection molding machine?
A two-platen injection molding machine uses a compact two-platen clamping system instead of the traditional toggle and four tie bars, generating high clamp force in a much shorter footprint. Two-platen presses are popular for large-tonnage applications (500–4,000+ tons) like automotive bumpers and pallets.
What are the advantages of a two-platen press?
Two-platen presses save floor space relative to their tonnage, provide uniform clamp force distribution and good platen parallelism for large molds, and offer fast, consistent clamp movements. They are favored for large-part and high-tonnage molding.
